Product Overview
The Stainless Steel Pneumatic Tank Bottom Diaphragm Valve is designed for hygienic and aseptic applications, commonly used in industries like pharmaceuticals, food, and biotechnology. Constructed from durable stainless steel, it features a flexible diaphragm for precise flow control and is pneumatically operated for efficient performance. This valve ensures complete tank drainage, minimizes contamination risk, and facilitates easy cleaning and sterilization. With no dead legs, it offers a smooth, reliable solution for critical fluid handling in sanitary environments.
Technical Parameters
▶Model Range: DN6~DN100
▶Pipeline Pressure: 0~1.6MPa
▶ControlPressure: 0.3-0.8MPa
▶Air Supply: Neutral gas orair,Compressed air
▶Valve Body Material: CF8, CF8M
▶Sealing Material: PTFE, RPTFE, PPL
▶Cylinder Material: Polyamide, CF8, Aluminum alloy
▶MediumTemperature: -20~180°C
▶AmbientTemperature: -20~80°C
▶Control Mode: Single-acting(NC/NO), Double-acting (NO/NC), Manual
▶Connection Method: Welded,Tri-Clamped, Flanged
▶Applicable Medium: Water, Oil, Gas,, etc.
Product Features
▶Hygienic Design: Constructed from high-quality 316L stainless steel, this valve is designed for sanitary applications, ensuring that no contaminants can enter the system. Its smooth surface minimizes the risk of bacterial growth and ensures easy cleaning and sterilization, making it ideal for the food, pharmaceutical, and biotechnology industries.
▶Pneumatic Actuation: The valve operates using compressed air, allowing for efficient, reliable, and precise control. Pneumatic operation provides fast actuation with minimal mechanical wear, ensuring long-term performance and reducing maintenance needs. It can be configured for single-acting or double-acting control to meet various operational requirements.
▶Complete Tank Drainage: Designed specifically for the bottom of tanks, this valve ensures that no residual liquid remains after the discharge process. This full drainage capability is crucial in applications where every drop of fluid must be removed to prevent contamination or waste, such as in pharmaceutical and food processing tanks.
▶Sterilization Capabilities: The valve can withstand high-temperature sterilization processes, making it suitable for industries that require regular cleaning and sterilization cycles. This feature helps maintain a sterile environment and reduces the risk of contamination, ensuring compliance with strict industry standards.
▶No Dead Legs: The valve is engineered to eliminate dead zones, where fluids can stagnate, preventing microbial growth and contamination. This feature is essential for maintaining the highest hygiene standards and ensuring complete fluid drainage, particularly in tanks used for sensitive applications like pharmaceuticals and food products.
Application Recommendations
▶Pharmaceutical Industry: Ideal for use in production and storage tanks where sterilization and contamination prevention are critical.
▶Food and Beverage Processing: Ensures hygienic fluid handling, complete drainage, and ease of cleaning in production systems.
▶Biotechnology: Supports aseptic environments, offering precise flow control and eliminating risks of cross-contamination.
▶Chemical Processing: Suitable for controlling and draining chemicals in tank systems, where reliability and safety are paramount. This valve guarantees efficient fluid management while maintaining sanitary conditions in sensitive processes.
