KST&OEM&ODM Brand
| Availability: | |
|---|---|
| Quantity: | |
Features
Efficiently filters water, dust, and oil from compressed air
Prolongs the lifespan of pneumatic components
Ensures clean and stable air supply
Common materials: aluminum alloy, stainless steel
Optional features: auto drain, explosion-proof housing, etc.
Technical Specifications
| Item | Specification |
| Model | AW2000-02 series (includes variants with/without valve core, transparent or metal bowl) |
| Port Size | 1/8" or 1/4" |
| Pressure Gauge Port Size | 1/8" |
| Applicable Fluid | Compressed Air |
| Operating Temperature Range | -5°C to 60°C (Not to freeze) |
| Proof Pressure | 1.5 MPa |
| Max. Working Pressure | 1.0 MPa |
| Set Pressure Range | 0.05 – 0.7 MPa |
| Filtration Grade | 5 μm |
| Drain Capacity | 8 cm³ |
| Cup Material | Metal Cup |
| Cup Protective Cover | Standard Steel Cover |
| Design Structure | With Overflow Type |
| Weight | 0.21 kg |
