Product Overview
The PLD-3000-XF Limit Switch is a high-performance mechanical switch designed for precise movement monitoring in hoisting and material handling equipment. Featuring dual SPDT mechanical switches, it ensures reliable operation with an explosion-proof rating of Ex d IIC T6 and an IP66 ingress protection. This limit switch operates within a wide temperature range of -25°C to 80°C, making it suitable for harsh industrial environments. It provides versatile cable connection options and helps improve safety by interrupting power when load limits are exceeded.
Product Parameters
| Mechanical Switch | 2 x SPDT(Mechanical switch double-knife double-throw) |
| Sensing Switch (Domestic) | SFB2-V3-Y Intrinsically Safe(8v) |
| P&F Sensing Switch | NJ2-V3-N Intrinsically Safe (8V) |
| P&F Sensing Switch | NBB3-V3-Z4(24V) |
| Sensing Switch (Domestic) | SBB2-V3-DA(24V) |
| Magnetic Sensing Switch (Domestic) | SBB3-V3-DA-CX |
| IP Rating | IP66 |
| Explosion-Proof Rating | Ex d IIC T6 |
| Operating Ambient temperature | -25~80℃ |
Cable Connection | （2xNPT1/2)(2×NPT3/4) M20×1.5(G1/2)(G3/4) |
Product Features
▶Dual SPDT Mechanical Switches: The PLD-3000-XF is equipped with dual SPDT (Single Pole Double Throw) mechanical switches. These switches provide highly reliable, precise control, making the product ideal for applications where accurate positioning and movement detection are crucial, such as hoisting and material handling equipment. The double-throw design enhances versatility and allows for broader functionality across various industrial setups.
▶Explosion-Proof and Hazardous Location Rated: Certified with an explosion-proof rating of Ex d IIC T6, the PLD-3000-XF is designed to be used safely in hazardous environments where there is a risk of flammable gases or vapors. This feature ensures the product maintains its integrity and safety even in extreme conditions, making it a reliable choice for industries like mining, oil and gas, and chemical processing.
▶IP66 Ingress Protection: The IP66 rating ensures that the PLD-3000-XF is resistant to dust and powerful water jets. This high level of protection guarantees the switch can withstand harsh environmental conditions, including exposure to water, dust, and moisture, ensuring long-lasting durability and performance in challenging industrial environments.
▶Wide Operating Temperature Range: With an operating temperature range of -25°C to 80°C, the PLD-3000-XF can function effectively in both cold and hot conditions. This wide temperature tolerance makes the switch ideal for diverse environments, from freezing cold warehouses to extreme heat in outdoor industrial settings.
▶Versatile Cable Connections: The PLD-3000-XF offers multiple cable connection options, including NPT1/2, NPT3/4, and M20×1.5, providing flexibility for installation. This allows users to choose the most suitable cable connection based on their specific system requirements, ensuring ease of integration with different industrial equipment and control systems.
Applications
▶Hoisting Equipment: The PLD-3000-XF Limit Switch is used for position control in hoisting equipment like winches, cranes, and gantries, ensuring safe operation by monitoring load limits.
▶Material Handling: It provides precise movement detection in material handling systems, improving efficiency and safety during operations involving large or heavy objects.
▶Pumping Systems: The switch helps control liquid levels in pumping systems, preventing overflow or dry running by accurately detecting fluid levels.
▶Industrial Machinery: Ideal for use in various industrial machines, the PLD-3000-XF ensures reliable operation under harsh conditions with high ingress protection and explosion-proof capabilities.
