PLD-IL100/PLD-IL200 Position Holding Valve

Model: PLD-IL100 (Position Holding Valve)

• Type: Single-acting

• Working Medium: Air

• Signal Pressure: MAX. 1.0 MPa

• Ambient Temperature: -40°C ~ 70°C

• Setting Pressure Range: 0.14 ~ 0.7 MPa

• Cut-off Back Pressure: MAX. 0.7 MPa

• Pressure Resolution Accuracy: 0.01 MPa

• Port Size: G1/4 or NPT1/4

• Material: Brass or Stainless Steel

Model: PLD-IL200 (Position Holding Valve)

• Type: Double-acting

• Working Medium: Air

• Signal Pressure: MAX. 1.0 MPa

• Ambient Temperature: -40°C ~ 70°C

• Setting Pressure Range: 0.14 ~ 0.7 MPa

• Cut-off Back Pressure: MAX. 0.7 MPa

• Pressure Resolution Accuracy: 0.01 MPa

• Port Size: G1/4 or NPT1/4

• Material: Brass or Stainless Steel
