KST&OEM&ODM Brand
| Availability: | |
|---|---|
| Quantity: | |
Application
▶ The pump is a sanitary side channel self-priming pump, suitable for food processing, pharmacy, and chemical industry.
▶ Specially designed for pumping materials containing air or gas. It can also be used for negative suction with prior priming as well as with filtration equipment.
▶ Suitable for pumping wine, oil, syrups, volatile products such as alcohol, acetone, and other solvents, or products at temperatures close to boiling point. The main use of this pump is for CIP (Clean-In-Place) return.
Technical Specifications
▶ Max flow: 30 m³/h (132 GPM)
▶ Max head: 40 H (m)
▶ Max pressure: 3 Bar (43 PSI)
▶ Max operating temperature: 120°C (248°F)
▶ Max revolutions: 1750 rpm
▶ Max suction height: 8 m (22 ft)
Design and Features
▶ Motor type: B35
▶Motor frequency: 50Hz / 60Hz
| Power (kW) | Voltage | Power (kW) | Voltage |
| 0.75 | 210V~230V / 50Hz 360V~400V / 50Hz 420V~460V / 60Hz | 4 | 360V~400V / 50Hz 630V~690V / 50Hz 420V~460V / 60Hz |
| 1.1 | 4.5 | ||
| 1.5 | 7.5 | ||
| 2.2 | 11 | ||
| 3 | 15 |
Options
▶ Mechanical seal in SiC/SiC
▶ Gaskets in FPM (Viton) and PTFE
▶ Inlet & outlet connections: Tri-Clamp, Thread, Flange, DIN, SMS, 3A, RJT
