▶ Powerful Functions: Intelligent type, proportional type, on-off type. Various signals and controls can be output and input.
▶ Compact Size: The volume is only about 35% that of similar products.
▶ Light Weight: Weight is about 30% that of similar products.
▶ High Torque: Aluminum alloy gear drive, precision machined, with large output torque.
▶ Manual Operation: Integrated manual operation mechanism, enables manual operation in case of power failure.
▶ Reliable Performance: High-strength worm gear design, 1500V insulation, anti-loosening screws, flame-retardant enclosure.
▶ Convenient Wiring: Multi-core waterproof cable, terminal blocks with wiring labels, 380V anti-reverse connection protection.
▶
▶ Safety Protection: Multiple protections including anti-loosening, waterproof, and anti-explosion.
▶ Positioning Accuracy: Dual limit protection, signal feedback, overload protection.
▶ Various Travel Times: Full travel times include 9s, 13s, 15s, 30s, 50s, 100s (customizable before ordering).
▶ Anti-Loosening Design: Anti-loosening fasteners, connector anti-fall measures.
▶ Optional Add-ons: Heater, temperature controller, anti-condensation device, travel time controller, torque protector, local/remote switch, etc.
Dimensions & Performance Parameters
| ltem | specification |
| Power Supply | DC24V, AC24V, AC110V, AC220V, AC380V |
| Output Torque | 55Nm (DC24V) 15s: 70 Nm / 28s: 100 Nm (AC110V, AC220V, AC380V) |
| 90° Operating Time | 8s (DC24V), 28s (AC series) |
| Rotation Angle Range | 0–90° |
| Power Consumption | 12W (DC/AC24V), 10W (AC110V/220V/380V) |
| Rated Current | DC24V: 1.00A AC24V: 2.20A AC110V: 0.36A AC220V: 0.20A AC380V: 0.15A |
| Total Weight | DC series: 2.3 kg AC series: 2.7 kg |
| Insulation Resistance | DC24V / AC24V: ≥100MΩ / 250VAC AC110V / AC220V / AC380V: ≥100MΩ / 500VAC |
| Dielectric Strength | DC24V: 500VAC (1 min) AC24V: 1000VAC (1 min) AC110V / AC220V: 1500VAC (1 min) AC380V: 1800VAC (1 min) |
| Protection Grade | IP67 |
| Mounting Orientation | 360° any-angle installation |
| Cable Entry | M18×1.5 waterproof cable gland, one for power cable and one for signal cable |
| Operating Environment | -25°C to +60°C |
| Control Types | R type, BS type, A type, RZ type, AZ type, ZT type, ZK type |
| Optional Features | Anti-condensation heater |
Company Profile
Wenzhou Kangtuo International Trade Co., Ltd. (Est. 2013) is a subsidiary of Kangsaite Automation Group Co., Ltd.(KST), headquartered in the “City of Valves” — Wenzhou, China. The company specializes in industrial and sanitary valves, with products exported to over 60 countries and widely used in petroleum, natural gas, chemical, and other industries. Backed by over 30 years of manufacturing expertise and internationally recognized certifications, we uphold the values of Professionalism, Integrity, and Win-Win Cooperation to be a trusted long-term partner for clients worldwide.
