KST multi turn electric actuator mechanism, suitable for gate valve, globe valve, and other multi-turn rotary valves, Equipped withlinear thrust unit, can control the direct stroke type control valve, Equipped with worm gear driving mechanism, can controlarge-diameter ball valve, buttertly valve and other partial rotaryvalves; Eouipped with reducer, base bracket and crank arm, cancontrol the damper and baffle valve.
Technical Parameters
| Item | Specification |
| Shell Material | Aluminum alloy shell, epoxy resin powder coating |
| Transmission Structure | First-class worm wheel and worm gear |
| Electric Parameters | Duty cycle: S2-15 min (on/off type); S4-25% (modulating type) Insulation class: F level (optional H level) |
| Valve Detection | Counting gear (basic type); absolute value encoder (integrated and intelligent types) |
| Moisture-Proof Heater | Standard configuration (for integrated and intelligent types) |
| Torque Range | 50–3500 Nm |
| Rotation Speed | 18–144 rpm |
| Anti-Corrosion Coating | Epoxy resin powder coating, salt mist test ≥ 168 hours |
| Silent Design | Noise level less than 65 dB |
| Protection Level | IP67 (basic type); IP68 (integrated and intelligent types) |
