Product Features
▶Castings offer excellent mechanical strength, capable of withstanding high pressure and impact loads over long periods.
▶Precision molds ensure consistent dimensions, allowing tight assembly tolerances and reliable valve performance.
▶Materials like WCB, CF8, CF8M, and other stainless or alloy steels provide good resistance to corrosion in various media.
▶Casting enables the production of complex internal and external structures that are difficult or impossible to machine.
▶Available in a wide range of materials (e.g., carbon steel, stainless steel, alloy steel), allowing customization for specific applications.
▶Casting is ideal for mass production, reducing machining time and overall production cost.
▶Cast components can endure high temperatures and abrasive flow, making them suitable for harsh environments.
▶Designs can include customer-specific logos, flow markings, and custom ports or shapes.
▶Valve castings often conform to standards like ASTM, ASME, ISO, DIN, or EN, ensuring compatibility and performance.
▶Optimized wall thickness and structure design provide good resistance to internal pressure surges.
Technical Parameters
| Model number | specification | Valve body Kg | Valve cover Kg | Gate plate Kg | Manual Bracket Kg | Bevel gear holder Kg | Manual Gross Weight/Kg |
American Standard Gate Valves Z40H-150LB | 2" | 10 | 4 | 1 | 15 | ||
| 3" | 18 | 6 | 2 | 26 | |||
| 4" | 29 | 9 | 4 | 42 | |||
| 5" | 35 | 11 | 4 | 50 | |||
| 6" | 46 | 15 | 6 | 67 | |||
| 8" | 72 | 23 | 12 | 107 | |||
| 10" | 113 | 31 | 19 | 10 | 173 | ||
| 12" | 169 | 47 | 30 | 14 | 27 | 260 | |
| 14" | 212 | 61 | 40 | 20 | 32 | 333 | |
| 16" | 276 | 99 | 51 | 24 | 34 | 450 | |
| 18" | 344 | 100 | 88 | 34 | 52 | 566 | |
| 20" | 437 | 135 | 90 | 35 | 61 | 697 | |
| 24" | 576 | 219 | 175 | 52 | 70 | 1022 | |
| Model number | specification | Valvebody Kg | Valve cover Kg | Gate plate Kg | Manual Bracket Kg | Bevel gear holder Kg | Manual Gross Weight/Kg |
| American Standard Gate ValvesZ40H-300LB | 2" | 16 | 6 | 1 | 23 | ||
| 3" | 31 | 10 | 3 | 44 | |||
| 4" | 47 | 15 | 4 | 66 | |||
| 5" | 70 | 20 | 4 | 94 | |||
| 6" | 93 | 27 | 7 | 127 | |||
| 8" | 145 | 42 | 15 | 202 | |||
| 10" | 212 | 55 | 22 | 14 | 28 | 303 | |
| 12" | 322 | 72 | 33 | 16 | 28 | 443 | |
| 14" | 475 | 112 | 61 | 26 | 40 | 674 | |
| 16" | 645 | 143 | 62 | 26 | 50 | 876 | |
| Model number | specification | Valvebody Kg | Valve cover Kg | Gate plate Kg | Manual Bracket Kg | Bevel gear holder Kg | Manual Gross Weight/Kg |
| American Standard Gate ValvesZ40H-600LB | 2" | 25 | 10 | 1 | 36 | ||
| 3" | 47 | 16 | 3 | 66 | |||
| 4" | 87 | 26 | 6 | 119 | |||
| 6" | 168 | 43 | 11 | 222 | |||
| 8" | 284 | 72 | 21 | 45 | 58 | 422 | |
| 10" | 504 | 123 | 31 | 27 | 41 | 685 | |
| Model number | specification | Valvebody Kg | Valve cover Kg | Gate plate Kg | Manual Bracket Kg | Bevel gear holder Kg | Manual Gross Weight/Kg |
| American Standard Gate ValvesZ40H-900LB | 2" | 59 | 18 | 4 | 81 | ||
| 3" | 67 | 22 | 4 | 93 | |||
| 4" | 114 | 33 | 6 | 153 |
